Advantages in power and polarization: 80mW high power meets medium and high power requirements (such as laser direct writing, high-intensity fluorescence excitation), with an extinction ratio of 18dB that far exceeds other models, ensuring more stable polarization states.
Low voltage adaptation: Operating voltage ranges from 5.0V to 6.0V, which is lower than that of the 488nm and 505nm models. It can be adapted to more conventional current sources, reducing the cost of power supply equipment.
Excellent spot quality: 3μm thin-core polarization-maintaining fiber + Gaussian spot output, suitable for applications with high requirements on spot size and uniformity (such as micro-structure processing).
| Central Wavelength (Range) | 400-410nm | Continuous Output Power | 80mW |
| Extinction Ratio | 18dB | Fiber Core Diameter | 3μm |
| Quantity | Price(USD) | Ship Date |
|---|---|---|
| 1-10 | TBD | |
| 10- | TBD |
