Comprehensive Specifications Table

Model	Table Size	Rotation Center	Travel Range	Drive Type	Guide Type	Load	Material
40mm Series (Micrometer)
VL-MG40-R40-L	40×40 mm	40±0.2 mm	±7∘	Micrometer (Left)	Cross Roller	29.4N (3kg)	Aluminum
VL-MG40-R60-L	40×40 mm	60±0.2 mm	±6∘	Micrometer (Left)	Cross Roller	29.4N (3kg)	Aluminum
VL-MG40-2A-L	40×40 mm	Common	α±7∘,β±6∘	Micrometer (Left)	Cross Roller	29.4N (3kg)	Aluminum
VL-MG40-R40-R	40×40 mm	40±0.2 mm	±7∘	Micrometer (Right)	Cross Roller	29.4N (3kg)	Aluminum
VL-MG40-R60-R	40×40 mm	60±0.2 mm	±6∘	Micrometer (Right)	Cross Roller	29.4N (3kg)	Aluminum
VL-MG40-2A-R	40×40 mm	Common	α±7∘,β±6∘	Micrometer (Right)	Cross Roller	29.4N (3kg)	Aluminum
40mm Series (Worm Gear)
VL-MG40-R40-C	40×40 mm	40±0.2 mm	±10∘	Worm Gear (Center)	Cross Roller	29.4N (3kg)	Aluminum
VL-MG40-R60-C	40×40 mm	60±0.2 mm	±6∘	Worm Gear (Center)	Cross Roller	29.4N (3kg)	Aluminum
VL-MG40-2A-C	40×40 mm	Common	α±10∘,β±6∘	Worm Gear (Center)	Cross Roller	29.4N (3kg)	Aluminum
60mm Series (Micrometer)
VL-MG60-R50-L	60×60 mm	50±0.2 mm	±6∘	Micrometer (Left)	Cross Roller	49N (5kg)	Aluminum
VL-MG60-R75-L	60×60 mm	75±0.2 mm	±4∘	Micrometer (Left)	Cross Roller	49N (5kg)	Aluminum
VL-MG60-2A-L	60×60 mm	Common	α±6∘,β±4∘	Micrometer (Left)	Cross Roller	49N (5kg)	Aluminum
VL-MG60-R50-R	60×60 mm	50±0.2 mm	±6∘	Micrometer (Right)	Cross Roller	49N (5kg)	Aluminum
VL-MG60-R75-R	60×60 mm	75±0.2 mm	±4∘	Micrometer (Right)	Cross Roller	49N (5kg)	Aluminum
VL-MG60-2A-R	60×60 mm	Common	α±6∘,β±4∘	Micrometer (Right)	Cross Roller	49N (5kg)	Aluminum
60mm Series (Worm Gear)
VL-MG60-R50-C	60×60 mm	50±0.2 mm	±10∘	Worm Gear (Center)	Cross Roller	49N (5kg)	Aluminum
VL-MG60-R75-C	60×60 mm	75±0.2 mm	±6∘	Worm Gear (Center)	Cross Roller	49N (5kg)	Aluminum
VL-MG60-2A-C	60×60 mm	Common	α±10∘,β±6∘	Worm Gear (Center)	Cross Roller	49N (5kg)	Aluminum
65mm Heavy/Precision
VL-MG65-R100	65×65 mm	100 mm	±10∘	Worm Gear (Center)	Dovetail	6 kg	Aluminum
VL-MG65-R76	65×65 mm	76 mm	±10∘	Worm Gear (Center)	Dovetail	6 kg	Aluminum
VL-MG65-R75-P	65×65 mm	75 mm	±10∘	Worm Gear (Center)	V-Groove+Ball	10 kg	Aluminum
VL-MG65-R50-P	65×65 mm	50 mm	±15∘	Worm Gear (Center)	V-Groove+Ball	10 kg	Aluminum
Specialty Series
VL-MG25-R32	25×25 mm	32.5 mm	±15∘	Worm Gear (Center)	Dovetail	2 kg	Aluminum
VL-MG25-R12	25×25 mm	12.5 mm	±30∘	Worm Gear (Center)	Dovetail	2 kg	Aluminum
VL-MG41-R16	41×27 mm	16 mm	±8∘	Micrometer (Center)	Dovetail	2 kg	Aluminum
VL-MG100-R66	100×100 mm	66.5 mm	±20∘	Worm Gear (Center)	Dovetail	15 kg	Aluminum
VL-MG40-R51-SP	Custom	51 mm	Custom	Custom	Custom	-	-
VL-MG60S-R35	60×60 mm	35 mm	±20∘	Worm Gear (Center)	Dovetail	5 kg	Aluminum
VL-MG60S-R60	60×60 mm	60 mm	±20∘	Worm Gear (Center)	Dovetail	5 kg	Aluminum

Manual Angular Position Stage

VL-MG Size Radius

VL-MG60-2A-L

VL-MG65-R50-P

VL-MG65-R100

VL-MG25-R12
