VL-R1-60 Series(40-160)
Industrial single-axis high-rigidity rotary stage
- Crossed roller bearing + preload design, rigidity is 10 times higher than traditional ones, and backlash is nearly zero.
- Reduction ratio 1-1536, load capacity up to 26700N, protection level IP65, resistant to harsh working conditions.
Overview
Industrial Precision Rotation Solutions
VenusLab VL-R1-60 Series (40-160) is an industrial single-axis electric rotary stage featuring high rigidity and wide adaptability. Crossed roller bearing with preload delivers 10× higher rigidity and near-zero backlash. 1-1536 adjustable gear ratio covers full specs, with max load 26700N and IP65 protection. Ideal for precision testing and harsh environments, it’s a cost-effective integration solution.
Features of VL-R1-60 Series (40-160)
- 90° staggered preloaded crossed roller bearing, with rigidity 10 times higher than traditional ones
- Secondary grinding of the turntable to control tolerance, planetary deceleration to reduce backlash to nearly zero clearance
- 1-1536 reduction ratio + standard photoelectric / optional limit switch
- IP65 grade skeleton oil seal, resistant to dust / splashing water
Dimension drawing of VL-R1-60 Series (40-160)
Serivce & Support
Explore Series
Model
Weight (kg)
Torsional Rigidity (N·m/arcmin)
Max Radial Force (N)
Max Overturning Moment (N·M)
Average Service Life (h)
Reference Load Capacity (kg)
Action
