Overview
Introduction to Infrared Heating Furnace：
It is mainly composed of an infrared radiator, a reflector, a control system, etc. It uses an infrared heating tube as the heating element and adopts infrared mirror reflection technology to concentrate and focus infrared radiation energy on the surface of the workpiece, making it heat up quickly. The temperature of this furnace can reach 1700℃, the long-term operating temperature is 1600℃, and the commonly used temperature is 1500℃. The temperature rise rate in the range is greater than 280℃/s, the voltage and power are 220 (380) V and 6-36kw, the heating ranges include point, line (columnar), and surface heating, the cooling method of the reflecting surface is water cooling, the temperature control accuracy is ±1℃, and the temperature display accuracy is 0.1℃.
Specifications
Application
Serivce & Support
Explore Series
Model
Net Weight
Overall Dimensions
Viewport Size
Sample Stage
Optical Path
Temperature Range
Action
