High-Performance Galvanometer Scanner

A universal galvanometer scanner series covering scenarios from microscopic imaging to high-power welding. Offers a full range of aperture options from 3mm to 20mm, combining rapid response with industrial-grade load stability.

Full Range Coverag
Micro-Radian Precision
Ultra-Low Drift Technology
Rapid Response

Overview

VenusLab™ Galvo Series: Setting New Standards for Precision Beam Steering

The VenusLab™ High-Performance Galvo Series is engineered to meet the most demanding beam steering requirements.

The series is divided into two camps: Type-S (Speed) for 3-7mm small apertures, pursuing 0.1ms extreme speed, ideal for laser display and bio-imaging; Type-P (Power) for 10-20mm large apertures, optimized for motor torque and thermal design, capable of driving large mirrors under high-power laser loads while maintaining dynamic performance.

Applications

Laser Scanning Confocal Microscopy
OCT & Ophthalmic Diagnosis
Optogenetics & Optical Tweezers
Laser Cleaning & Rust Removal
Precision Laser Welding
Marking-on-the-Fly

Interfaces & Compatibility

Driver Protocol: All series support analog ± 5V or ± 10V input, compatible with standard XY2-100 protocol.

Power Requirements: Recommended ± 15V for Type-S, and ± 24V for Type-P for optimal torque output.

Technical Specifications

Group A: High-Speed Imaging Models (3mm - 7mm)

Parameter	VenusLab-8107	VenusLab-9215
Best For	Cost-Effective Imaging	High-End Scanning
Aperture	3 / 5 / 7 mm	3 / 5 / 7 mm
Step Response (0.1°)	≤ 0.14 ms	< 0.13 ms (Faster)
Tracking Error	0.1 ms	0.09 ms
Linearity	99.90%	99.90%
Repeatability	< 8 µRad	< 8 µRad
Operating Voltage	±15V / ±24V	±15V / ±24V
Average Current	2.0 A (Max)	3.4 A (Max)
Scan Angle	± 20°	± 20°

Group B: High-Load Industrial Models (10mm - 20mm)

Parameter	VenusLab-9310	VenusLab-9230
Best For	Precision Marking	Welding & Cleaning
Aperture	10 mm	15 / 20 mm
Step Response (0.1°)	< 0.2 ms	< 0.35 ms
Torque Constant	-	High Torque Optimized
Linearity	99.90%	99.90%
Scale Drift	< 50 PPM/°C	< 50 PPM/°C
Signal Scale Factor	0.5 V/°	5.5 V/° (Special)
Peak Current	20 A	20 A
Operating Voltage	±15V / ±24V	±24V Recommended
