Low Dark Current Silicon PIN Photodiode（350-1060nm）
产品编号: PDCT02-201
Large photosensitive area (Φ1.5mm) increases light input, adapts to signal acquisition in low-light environments, and enhances signal strength without relying on light-gathering components;
2pin pins simplify integration, the flat window ensures uniformity of optical signals, and the dark current (Max 20pA) remains at a low level in the large photosensitive area model, balancing light input and signal accuracy
注意事项
- 产品图片仅供参考，并不代表所有产品。
已配置规格
| Photosensitive Area Size (mm) | Φ1.5 | Window Type | Optical Glass/Flat |
| Max Dark Current (VR=10mV) (pA) | 20 (Max) | Junction Capacitance (VR=0V,f=100kHz) (pF) | 20 (Typ) |
| Rise Time (RL=1kΩ,VR=0V) (μs) | 0.07 (Typ) | Shunt Resistance (VR=10mV) (GΩ) | - |
浏览全部型号
Low Dark Current Silicon PIN Photodiode（350-1060nm）
PDCT01-201
TO18 package, silicon PIN material, spectral response range 350~1060nm, optimized visible light response.
Low Dark Current Silicon PIN Photodiode（350-1060nm）
PDCT01-202
Photosensitive area size: 1.1×1.1mm, optical window type is optical glass ball window, number of pins: 2pin;
Low Dark Current Silicon PIN Photodiode（350-1060nm）
PDCT01-205
Photosensitive area size: 1.1×1.1mm, light window type is optical glass flat window, number of pins: 3pin.
