It has better low-light detection accuracy, suitable for detecting extremely weak light signals at the μW level; it has a faster high-frequency response speed, capable of capturing pulsed near-infrared signals below 1MHz (such as infrared remote control coding, short-distance infrared communication feedback).
It has strong versatility in the medium and short near-infrared range, and can be adapted to multiple near-infrared detection scenarios without replacing components.
| Photosensitive Area Size (mm) | 5.8×5.8 | Window Material | Resin |
| Dark Current (V_R=10mV, Typ./Max., pA) | 60/360 | Photosensitivity (Typ., A/W) | 0.43@633nm, 0.62@920nm |
| Junction Capacitance (f=100kHz,V_R=0V, Typ./Max., pF) | 400/500 | Rise Time (R_L=1kΩ,V_R=0V, Typ., μs) | 0.9 |
| Quantity | Price(USD) | Ship Date |
|---|---|---|
| 1-10 | TBD | |
| 10- | TBD |
