VL Quick-Connect Type Fiber-Coupled Laser
Overview
Introduction:
Venuslab Quick-Connect Type Fiber-Coupled Laser is a modular laser solution positioned for "low-to-medium power and multi-spectral adaptability". Through systematic wavelength coverage and power gradient design, it has built a complete laser output system from ultraviolet to near-infrared. This series includes over 30 core models, with a wavelength range covering 405nm (near-ultraviolet) to 1064nm (near-infrared) and power levels distributed in a stepped manner from 5mW to 1000mW.
All models adopt multi-mode fiber (MF) output and FP cavity structure design, making them suitable for the differentiated needs of monochromatic lasers in multiple scenarios such as scientific research experiments, industrial testing, and biomedical applications.
Features:
- Multimode Fiber (MF) output + FP cavity structure + CTP packaging
- Wavelength range coverage 405nm (near-ultraviolet) to 1064nm (near-infrared)
- High stability and long service life
- Multi-dimensional adaptation reduces integration barriers
- Unified pin definition simplifies circuit integration
Specifications
Dimensions
Selection Table
Serivce & Support
Explore Series
Model
Threshold Current (mA)
Operating Voltage (V)
Continuous Output Power(mW)
Operating Current (mA)
Central Wavelength(nm)
Package Size
Action
VLFL-405-100-A-1
40-70
5.0-6.0
100
150-180
400-405-410
A-1: Φ8×10.5
VLFL-405-100-A-3
40-70
5.0-6.0
100
150-180
400-405-410
A-3: 8.5-7.5-12
VLFL-405-100-A-4
40-70
5.0-6.0
100
150-180
400-405-410
A-4：10×10×11
VLFL-405-100-A-5
40-70
5.0-6.0
100
150-180
400-405-410
A-5: 10-10-13.5
VLFL-405-300-A-1
140-200
4.5-5.5
300
250-400
400-405-410
A-1：Φ8×10.5
VLFL-405-300-A-3
140-200
4.5-5.5
300
250-400
400-405-410
A-3: 8.5-7.5-12
VLFL-405-300-A-4
140-200
4.5-5.5
300
250-400
400-405-410
A-4：10×10×11
VLFL-405-300-A-5
140-200
4.5-5.5
300
250-400
400-405-410
A-5: 10-10-13.5
VLFL-405-500-A-1
125-225
5.0-6.0
500
650-750
400-405-410
A-1：Φ8×10.5
VLFL-405-500-A-3
125-225
5.0-6.0
500
650-750
400-405-410
A-3: 8.5-7.5-12
VLFL-405-500-A-4
125-225
5.0-6.0
500
650-750
400-405-410
A-4：10×10×11
VLFL-405-500-A-5
125-225
5.0-6.0
500
650-750
400-405-410
A-5: 10-10-13.5
VLFL-450-60-A-1
22
5.3
60
110
445-450-455
A-1：Φ8×10.5
VLFL-450-1000-A-1
22
5.3
1000
110
445-450-455
A-1：Φ8×10.5
VLFL-488-60-A-1
22
5.3
60
110
483-488-493
A-1：Φ8×10.5
VLFL-505-80-A-1
60
6.5
80
140
500-505-510
A-1：Φ8×10.5
VLFL-520-60-A-1
60-90
6.6-7.7
60
160-180
515-520-525
A-1：Φ8×10.5
VLFL-520-100-A-1
70-95
6.7-8.0
100
160-260
515-520-525
A-1：Φ8×10.5
VLFL-520-200-A-1
80
6.5
200
240
515-520-525
A-1：Φ8×10.5
VLFL-638-130-A-1
35-55
2.2-3.0
130
200-220
633-638-643
A-1：Φ8×10.5
VLFL-638-150-A-1
35-55
2.2-3.0
150
200-220
633-638-643
A-1：Φ8×10.5
VLFL-660-100-A-1
50-65
2.5-3.0
100
155-165
655-660-665
A-1：Φ8×10.5
VLFL-660-100-A-2
50-65
2.5-3.0
100
155-165
655-660-665
A-2：Φ6.4/FC
VLFL-670-5-A-1
140-200
4.5-5.5
5
250-400
665-670-675
A-1：Φ8×10.5
VLFL-685-50-A-1
35-60
2.7-3.0
50
100-140
680-685-690
A-1：Φ8×10.5
VLFL-785-60-A-1
30-50
2.0-2.5
60
120-160
780-785-790
A-1：Φ8×10.5
VLFL-808-100-A-1
35-45
3
100
160-170
803-808-813
A-1：Φ8×10.5
VLFL-830-100-A-1
55-80
1.8-2.6
100
170-240
825-830-835
A-1：Φ8×10.5
VLFL-850-100-A-1
55-80
1.8-2.7
100
180-240
845-850-855
A-1：Φ8×10.5
VLFL-905-100-A-1
25-50
1.9-2.4
100
130-170
900-905-910
A-1：Φ8×10.5
VLFL-940-100-A-1
20-40
1.8-2.4
100
270-320
935-940-945
A-1：Φ8×10.5
VLFL-980-100-A-1
40-50
1.0-2.1
100
165-195
975-980-985
A-1：Φ8×10.5
VLFL-1064-50-A-1
15-18
1.8-2.0
50
120-135
1060-1064-1070
A-1：Φ8×10.5
