VenusLab Piezo Motor Stages

Compact Nanometer Motion Control Solutions

Integrated optical encoders for stable nanoscale positioning.
100mm/s response + high load capacity in an ultra-compact form factor.

Download

Data Sheet

Overview

Precision Beyond Size

VenusLab Piezo Motor Stages utilize advanced ultrasonic piezo drive technology to deliver smooth, high-speed motion with zero backlash. Engineered for space-constrained applications, these stages provide a robust solution for researchers and engineers requiring heavy-duty performance and sub-micron precision without compromising on workspace.

Applications

Precision Optical Alignment
Semiconductor Inspection
Bio-Micromanipulation
Laser Focus Control

Technical Specifications

Model (VenusLab)	Travel Range (mm)	Drive Mechanism	Max Load (kg)	Max Speed (mm/s)	Min Step (nm)	Repeatability (nm)	Position Sensor	Material	Weight (kg)
VL-VS-1025TG	25	Piezo Motor	5	1	50	+/-200	Optical Grating	Aluminum Alloy	2.55
VL-VS-0812	5-12	Piezo Motor	0.5-1.5	50	50	+/-200	Optical Grating	Aluminum Alloy	1.0
VL-VS-0606	1-6	Piezo Motor	0.5	100	50	+/-200	Optical Grating	Aluminum Alloy	0.5
VL-VS3-0825C	12-25	Piezo Motor	1-2	50	50	+/-200	Optical Grating	Aluminum Alloy	1.75
VL-LS3-1020Z	10-40	Piezo Motor	1-4	100	50	+/-200	Optical Grating	Aluminum Alloy	1.3
VL-LS2-0910Z	10-20	Piezo Motor	1-2	100	50	+/-200	Optical Grating	Aluminum Alloy	0.52
VL-LS2-0610Z	10-20	Piezo Motor	1-2	100	50	+/-200	Optical Grating	Aluminum Alloy	0.35
VL-LS2-0606Z	2-6	Piezo Motor	0.3-0.5	100	50	+/-200	Optical Grating	Aluminum Alloy	0.25
