The combination of small size and deep ultraviolet detection capability avoids the space occupation problem of large-sized quartz window models; the quartz window is resistant to ultraviolet aging, and the light transmittance attenuation after continuous ultraviolet irradiation is lower than that of optical glass, extending the service life of the device.
It is suitable for handheld ultraviolet sterilization effect detectors (for detecting 254nm sterilizing ultraviolet light) and small water quality ultraviolet disinfection monitoring modules, expanding "light power detection" to the deep ultraviolet field.
| Photosensitive Area Size (mm) | 2.6×2.6 | Window Material | Quartz/Flat Window |
| Spectral Response Range (nm) | 250~1060 | Dark Current (Max, pA) | 30 |
| Junction Capacitance (Max, pF) | 80 | Equivalent Noise Power (W/Hz¹/²) | 6.0×10⁻¹⁵ |
| Quantity | Price(USD) | Ship Date |
|---|---|---|
| 1-10 | TBD | |
| 10- | TBD |
