Further improve the resolution at medium and high magnifications to adapt to finer sub-micron structures, and balance the working distance and depth of field.
Applications:
Suitable for 3D topography detection of MEMS devices (such as microbeams, microvalves), or microscopic analysis of grain boundaries in metal materials (observing atomic arrangement distortions).
| NA | 0.4 | WD | 4.6mm |
| R | 0.69um | ±D.F | 1.72um |
